Slim Duo Fix IP44 8W 830/840 DA2 WH
Slim Duo Fix Downlight 8W 3000K/4000K 650lm Beam angle Extreme wide beam >80°; DALI-2; IP44; IK07; Protection cl. II; L70B50 100000h; LED not exchangeable; CRI>80; SDCM5; Suitable for through wiring; 5x2.5mm²; Housing al; Colour wh; Cover Plastic, opal
The robust Slim Duo Fix is a downlight with a changeable colour temperature and good dimmer features, intended especially for renovation projects. With its opal diffuser, the Slim Duo solution discreetly blends in with a white ceiling. It is designed for use in toilet facilities, corridors and lobbies.
Die-cast aluminium housing and acrylic diffuser
White, RAL 9010.
Protection class II.
Recessed mounting on a ceiling.
Linkable: Dimmable and Casambi-models max 3 x 2,5 mm2. Dali-2 models max 5 x 2,5 mm2. Spring terminal blocks.
Installation height 2–4 m.
Colour temperatures 3000 K and 4000 K (changeable from the luminaire). CRI > 80 / Ra > 80.
MacAdam 5 SDCM.
IP20/IP44.
IK07.
Integrated LED 8 W: 3000 K, 600 lm / 4000 K, 650 lm.
Dimming: rising- and trailing-edge control, Dali-2 with push-button control (230 V); and Casambi.
Ambient temperature range 0 … 25 °C.
Rated lifetime L70 100 000 h (Ta25°C).
Rated lifetime L80 100 000 h (Ta25°C).
- Code
- A2SLJA-DALI
Downloads
Technical info
- GTIN
- 6435200272126
- Airam code
- A2SLJA-DALI
- Code
- A2SLJA-DALI
- Installation height (max) (mm)
- 4000
- Length (mm)
- 110
- Fit for workplace acc. EN 12464-1
- No
- Adjustability
- Not adjustable
- Suitable for suspended mounting
- No
- Emergency function monitoring system
- None
- Luminaire efficacy (max) (lm/W)
- 82
- Colour of light (alphanumeric)
- White
- Lamp holder
- Other
- Suitable for clamp-mounting
- No
- Dimming Zigbee
- No
- Colour temperature (max) (K)
- 4000
- Dimming leading edge
- No
- Surface brushed
- No
- Number of poles
- 5
- Stroboscope effect value SVM
- 0.4
- Connectable conductor cross section (min) (mm²)
- 1.5
- Total harmonic distortion
- 20
- Compatible with Google Assistant
- No
- Connectable conductor cross section (max) (mm²)
- 2.5
- Conductor cross section (mm²)
- 2.5
- Rated life time L70/B50 at 25 °C (h)
- 100000
- Suitable for light-track mounting
- No
- Dimming DMX
- No
- Containing product according to 2019/2020/EU
- Yes
- With light sensor
- No
- Photobiological safety according to EN 62471
- RG0
- Maximum system power (W)
- 8
- With presence indicator
- No
- Emergency power supply system
- None
- Dimmable
- Yes
- Suitable for ceiling mounting
- Yes
- Exchangeable control gear
- Yes
- Rated luminous flux according to IEC 62722-2- 1 (max) (lm)
- 650
- Dimming Sine Wave Reduction
- No
- Dimming programmable
- Yes
- Built-in width (min) (mm)
- 90
- Installation height (min) (mm)
- 2000
- Housing colour
- White
- Emergency power supply integrated
- No
- Lumen maintenance at median useful life of 50,000 hrs at 25 °C ambient (tq) (%)
- 70
- Compatible with Casambi
- No
- Beam angle adjustable
- No
- Degree of protection (IP), rear side
- IP20
- Recess diameter (min) (mm)
- 90
- Filament test according to IEC 60695-2-11
- 650 °C - 30 s
- Lumen maintenance at median useful life of 35,000 hrs at 25 °C ambient (tq) (%)
- 80
- Built-in width (mm)
- 90
- Suitable for number of lamps
- 1
- Control gear included
- Yes
- Dimming RF
- No
- Rated ambient temperature acc. IEC62722-2-1 (min) (°C)
- 0
- Effective luminous flux (lm)
- 650
- Rated life time L80/B50 at 25 °C
- 100000
- IFTTT support available
- No
- Failure rate at median useful life of 50,000 hrs at 25 °C ambient (tq) (%)
- 10
- Recess diameter (max) (mm)
- 100
- Luminaire with limited surface temperature, class "D“ in acc. with EN 60598-2-24
- No
- Dimming potentiometer (integrated)
- No
- Impact strength
- IK07
- Width (mm)
- 110
- Suitable for surface mounting
- No
- Luminaire efficacy (lm/W)
- 82
- Dimming with push-button
- Yes
- Energy efficiency class of light source according to EU regulation 2019/2015
- F
- Outer diameter (mm)
- 110
- With movement sensor
- No
- Nominal voltage (max) (V)
- 240
- Nominal current (min) (mA)
- 200
- Type of wiring
- Suitable for through wiring
- Built-in width (max) (mm)
- 90
- Dimming 1-10 V
- No
- Colour rendering index (CRI/Ra)
- 80-89
- Dimming DSI
- No
- Luminous flux (min) (lm)
- 600
- Light outlet
- Direct
- Failure rate at median useful life of 35,000 hrs at 25 °C ambient (tq) (%)
- 5
- Suitable for lamp power (min) (W)
- 8
- Suitable for pedestal/floor mounting
- No
- No dimming function
- No
- Degree of protection (IP), front side
- IP44
- Flickering value Pst LM
- 1
- Bluetooth operated
- No
- Reflector
- None
- Dimming 0-10 V
- No
- Connection type
- Screwless terminal
- Light source included
- Yes
- Max. number of luminaires per miniature circuit breaker C16
- 224
- Lamp type
- LED not exchangeable
- Light distributor
- None
- Luminaire may be covered with thermally insulating material
- No
- Total harmonic distortion (THD) (%)
- 20
- Built-in height/depth (mm)
- 38
- Dimming DALI-2
- Yes
- Nominal voltage (min) (V)
- 220
- Suitable for recessed mounting
- Yes
- Surface protection
- Powder coating
- Dimming manufacturer's proprietary system
- No
- Type of control gear
- LED operating device current-controlled
- Colour temperature (min) (K)
- 3000
- Degree of protection (IP)
- IP44
- Suitable for traverse mounting
- No
- Power factor
- 0.9
- Beam angle
- Extreme wide beam >80°
- Rated luminous flux according to IEC 62722-2- 1 (min) (lm)
- 600
- Lumen setting adjustable
- No
- Suitable for lamp power (max) (W)
- 8
- Protection class according to IEC 61140
- II
- Dimming DALI
- Yes
- Luminous flux (max) (lm)
- 650
- Light sharing
- Symmetric
- Luminaire efficacy (min) (lm/W)
- 82
- Voltage type
- AC
- Suitable for low voltage cable system
- No
- Colour temperature switchable
- Discrete positions
- Built-in length (mm)
- 90
- Compatible with Apple HomeKit
- No
- Dimming LineSwitch
- No
- Housing material
- Aluminium
- Constant luminous flux control
- No
- Compatible with Amazon Alexa
- No
- Height/depth (mm)
- 41
- Rated ambient temperature acc. IEC62722-2-1 (max) (°C)
- 25
- Colour consistency (McAdam ellipse)
- SDCM5
- Dimming trailing edge
- No
- Suitable for wall mounting
- No
- Dimming Touch and Dim
- No
- Dimming mains voltage modulation
- No
- Nominal current (max) (mA)
- 200
- Cover material
- Plastic, opal
- Max. number of luminaires per miniature circuit breaker B16
- 112
Product versions
Slim Duo Fix Dim
| Item description | Code | |
|---|---|---|
| Slim Duo Fix IP44 8W 830/840 DIM WH | 4245361 |
Slim Duo Fix Dali
| Item description | Code | |
|---|---|---|
| Slim Duo Fix IP44 8W 830/840 DA2 WH | A2SLJA-DALI |
Slim Duo Fix Casambi
| Item description | Code | |
|---|---|---|
| Slim Duo Fix IP44 8W 830/840 CA WH | A2SLJA-CA |
