Blitz Sq M Double
Blitz Sq M Double is a surface-mounted wall luminaire with a rectangular design, and it distributes light in two directions. The luminaire is suitable for indoor and outdoor use. Integrated LED. Available with three different beams. High-quality surface treatment, stainless steel screws.
Aluminium housing and transparent glass diffuser.
Anthracite, silver, black and white.
Protection class I.
Surface mounting.
Not linkable, 3 x 2.5 mm2.
Installation height 0.5–4 m.
Integrated LED 31W / 3180–3580 lm.
IP65.
IK07.
On/off.
Ambient temperature range -25 … 25 °C
Rated lifetime L70 50,000 h (Ta25°C).
Power source service life 50,000 h.
AN = anthracite, SI = silver, BK = black, WH = white.
Also available in Corten colour on a project-specific basis.
Technical info
| Item description | Code | Electrical number (FIN) | Colour temperature | Luminous flux | Power | Dimensions | |||
|---|---|---|---|---|---|---|---|---|---|
| Blitz Sq M Double anthracite | |||||||||
|
Blitz Sq M Double 31W/830 16D ANT | 4511616 |
4511616 |
3000K |
3180lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/830 40D ANT | 4511626 |
4511626 |
3000K |
3290lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/830 74D ANT | 4511636 |
4511636 |
3000K |
3400lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/840 16D ANT | 4511621 |
4511621 |
4000K |
3350lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/840 40D ANT | 4511631 |
4511631 |
4000K |
3460lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/840 74D ANT | 4511641 |
4511641 |
4000K |
3580lm |
31W |
130x130x220mm |
||
| Item description | Code | Electrical number (FIN) | Colour temperature | Luminous flux | Power | Dimensions | |||
|---|---|---|---|---|---|---|---|---|---|
| Blitz Sq M Double black | |||||||||
|
Blitz Sq M Double 31W/830 16D BK | 4511618 |
4511618 |
3000K |
3180lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/830 40D BK | 4511628 |
4511628 |
3000K |
3290lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/830 74D BK | 4511638 |
4511638 |
3000K |
3400lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/840 16D BK | 4511623 |
4511623 |
4000K |
3350lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/840 40D BK | 4511633 |
4511633 |
4000K |
3460lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/840 74D BK | 4511643 |
4511643 |
4000K |
3580lm |
31W |
130x130x220mm |
||
| Item description | Code | Electrical number (FIN) | Colour temperature | Luminous flux | Power | Dimensions | |||
|---|---|---|---|---|---|---|---|---|---|
| Blitz Sq M Double white | |||||||||
|
Blitz Sq M Double 31W/830 16D WH | 4511619 |
4511619 |
3000K |
3180lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/830 40D WH | 4511629 |
4511629 |
3000K |
3290lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/830 74D WH | 4511639 |
4511639 |
3000K |
3400lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/840 16D WH | 4511624 |
4511624 |
4000K |
3350lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/840 40D WH | 4511634 |
4511634 |
4000K |
3460lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/840 74D WH | 4511644 |
4511644 |
4000K |
3580lm |
31W |
130x130x220mm |
||
| Item description | Code | Electrical number (FIN) | Colour temperature | Luminous flux | Power | Dimensions | |||
|---|---|---|---|---|---|---|---|---|---|
| Blitz Sq M Double silver | |||||||||
|
Blitz Sq M Double 31W/830 16D SI | 4511617 |
4511617 |
3000K |
3180lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/830 40D SI | 4511627 |
4511627 |
3000K |
3290lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/830 74D SI | 4511637 |
4511637 |
3000K |
3400lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/840 16D SI | 4511622 |
4511622 |
4000K |
3350lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/840 40D SI | 4511632 |
4511632 |
4000K |
3460lm |
31W |
130x130x220mm |
||
|
Blitz Sq M Double 31W/840 74D SI | 4511642 |
4511642 |
4000K |
3580lm |
31W |
130x130x220mm |
||
