Blitz Sq M Double 31W/830 16D ANT
Blitz Sq M Double Outdoors wall luminaire 31W 3000K 3180lm No dim; IP65; IK07; Protection cl. I; L70B50 50000h; LED not exchangeable; CRI>80; SDCM3; Ending; 3x2.5mm²; Housing al; Colour ant; Cover Glass transparent; C16 max. 35
Blitz Sq M Double is a surface-mounted wall luminaire with a rectangular design, and it distributes light in two directions. The luminaire is suitable for indoor and outdoor use. Integrated LED. Available with three different beams. High-quality surface treatment, stainless steel screws.
Aluminium housing and transparent glass diffuser.
Anthracite, silver, black and white.
Protection class I.
Surface mounting.
Not linkable, 3 x 2.5 mm2.
Installation height 0.5–4 m.
Integrated LED 31W / 3180–3580 lm.
IP65.
IK07.
On/off.
Ambient temperature range -25 … 25 °C
Rated lifetime L70 50,000 h (Ta25°C).
Power source service life 50,000 h.
AN = anthracite, SI = silver, BK = black, WH = white.
Also available in Corten colour on a project-specific basis.
- Code
- 4511616
Downloads
Technical info
- Electrical number (FIN)
- 4511616
- GTIN
- 6435200222978
- Airam code
- B5BQGA
- Code
- 4511616
- Compatible with Apple HomeKit
- No
- Beam angle adjustable
- No
- Dimming 1-10 V
- No
- With light sensor
- No
- Connectable conductor cross section (min) (mm²)
- 1.5
- With air slots
- No
- Compatible with Google Assistant
- No
- Luminaire efficacy (max) (lm/W)
- 102
- Light sharing
- Symmetric
- Beam angle
- Narrow beam 10-20°
- Fit for workplace acc. EN 12464-1
- No
- Impact strength
- IK07
- Stroboscope effect value SVM
- 0.4
- With presence indicator
- No
- Dimming DSI
- No
- Rated luminous flux according to IEC 62722-2- 1 (max) (lm)
- 3180
- Effective luminous flux (lm)
- 3180
- Constant luminous flux control
- No
- Dimming trailing edge
- No
- Light source included
- Yes
- Rated luminous flux according to IEC 62722-2- 1 (min) (lm)
- 3180
- No dimming function
- Yes
- Max. number of luminaires per miniature circuit breaker B16
- 23
- Housing material
- Aluminium
- Width (mm)
- 130
- Suitable for suspended mounting
- No
- Type of grid
- None
- Flickering value Pst LM
- 1
- Bluetooth operated
- No
- Outer diameter (mm)
- 130
- Colour temperature switchable
- No
- Dimming DMX
- No
- Compatible with Casambi
- No
- Lamp holder
- Other
- Type of control gear
- LED operating device current-controlled
- Suitable for lamp power (min) (W)
- 31
- Dimming programmable
- No
- IFTTT support available
- No
- Dimming mains voltage modulation
- No
- Light distributor
- Reflector
- Dimming RF
- No
- Emergency function monitoring system
- None
- Luminaire efficacy (lm/W)
- 102
- Dimming 0-10 V
- No
- Total harmonic distortion (THD) (%)
- 20
- Height/depth (mm)
- 220
- Failure rate at median useful life of 50,000 hrs at 25 °C ambient (tq) (%)
- 10
- Exchangeable control gear
- Yes
- Voltage type
- AC
- Length (mm)
- 130
- Dimming Touch and Dim
- No
- Photobiological safety according to EN 62471
- RG0
- Dimming potentiometer (integrated)
- No
- Filament test according to IEC 60695-2-11
- 650 °C - 30 s
- Suitable for wall mounting
- Yes
- Nominal current (min) (mA)
- 530
- With mounting material
- Yes
- Suitable for surface mounting
- Yes
- Colour of light (alphanumeric)
- White
- Colour temperature (max) (K)
- 3000
- Rated life time L70/B50 at 25 °C (h)
- 50000
- Dimming Sine Wave Reduction
- No
- Colour rendering index (CRI/Ra)
- 80-89
- Colour consistency (McAdam ellipse)
- SDCM3
- Nominal voltage (min) (V)
- 220
- Connectable conductor cross section (max) (mm²)
- 2.5
- Dimming leading edge
- No
- Dimming DALI-2
- No
- Suitable for recessed mounting
- No
- Failure rate at median useful life of 35,000 hrs at 25 °C ambient (tq) (%)
- 5
- Max. number of luminaires per miniature circuit breaker C16
- 35
- Rated life time L80/B50 at 25 °C
- 35000
- Containing product according to 2019/2020/EU
- Yes
- Control gear included
- Yes
- Luminaire with limited surface temperature, class "D“ in acc. with EN 60598-2-24
- No
- With movement sensor
- No
- Lumen maintenance at median useful life of 35,000 hrs at 25 °C ambient (tq) (%)
- 80
- Degree of protection (IP), front side
- IP65
- Type of wiring
- Ending
- Dimming with push-button
- No
- Emergency power supply system
- None
- Protection class according to IEC 61140
- I
- Degree of protection (IP), rear side
- IP65
- Power factor
- 0.9
- Dimming Zigbee
- No
- Dimming DALI
- No
- Max. number of luminaires per miniature circuit breaker C10 (MCB)
- 23
- Suitable for clamp-mounting
- No
- Dimming LineSwitch
- No
- Compatible with Amazon Alexa
- No
- Dimmable
- No
- Cover material
- Glass transparent
- With switch
- No
- Total harmonic distortion
- 20
- Conductor cross section (mm²)
- 2.5
- Rated ambient temperature acc. IEC62722-2-1 (min) (°C)
- -25
- Suitable for lamp power (max) (W)
- 31
- Nominal voltage (max) (V)
- 240
- Colour temperature (min) (K)
- 3000
- Luminaire efficacy (min) (lm/W)
- 102
- Suitable for light line configuration
- No
- Energy efficiency class of light source according to EU regulation 2019/2015
- C
- Housing colour
- Anthracite
- Number of poles
- 3
- Suitable for emergency lighting
- No
- Rated ambient temperature acc. IEC62722-2-1 (max) (°C)
- 25
- Suitable for number of lamps
- 1
- Dimming manufacturer's proprietary system
- No
- Light outlet
- Direct/indirect
- Housing surface protection
- Powder coating
- Suitable for ceiling mounting
- No
- Lamp type
- LED not exchangeable
- Nominal current (max) (mA)
- 530
- Lumen maintenance at median useful life of 50,000 hrs at 25 °C ambient (tq) (%)
- 70
- Connection type
- Screwed terminal
- Emergency power supply integrated
- No
- Degree of protection (IP)
- IP65
- Maximum system power (W)
- 31
- Lumen setting adjustable
- No
Product versions
Blitz Sq M Double anthracite
| Item description | Code | |
|---|---|---|
| Blitz Sq M Double 31W/830 16D ANT | 4511616 |
|
| Blitz Sq M Double 31W/830 40D ANT | 4511626 |
|
| Blitz Sq M Double 31W/830 74D ANT | 4511636 |
|
| Blitz Sq M Double 31W/840 16D ANT | 4511621 |
|
| Blitz Sq M Double 31W/840 40D ANT | 4511631 |
|
| Blitz Sq M Double 31W/840 74D ANT | 4511641 |
Blitz Sq M Double black
| Item description | Code | |
|---|---|---|
| Blitz Sq M Double 31W/830 16D BK | 4511618 |
|
| Blitz Sq M Double 31W/830 40D BK | 4511628 |
|
| Blitz Sq M Double 31W/830 74D BK | 4511638 |
|
| Blitz Sq M Double 31W/840 16D BK | 4511623 |
|
| Blitz Sq M Double 31W/840 40D BK | 4511633 |
|
| Blitz Sq M Double 31W/840 74D BK | 4511643 |
Blitz Sq M Double white
| Item description | Code | |
|---|---|---|
| Blitz Sq M Double 31W/830 16D WH | 4511619 |
|
| Blitz Sq M Double 31W/830 40D WH | 4511629 |
|
| Blitz Sq M Double 31W/830 74D WH | 4511639 |
|
| Blitz Sq M Double 31W/840 16D WH | 4511624 |
|
| Blitz Sq M Double 31W/840 40D WH | 4511634 |
|
| Blitz Sq M Double 31W/840 74D WH | 4511644 |
Blitz Sq M Double silver
| Item description | Code | |
|---|---|---|
| Blitz Sq M Double 31W/830 16D SI | 4511617 |
|
| Blitz Sq M Double 31W/830 40D SI | 4511627 |
|
| Blitz Sq M Double 31W/830 74D SI | 4511637 |
|
| Blitz Sq M Double 31W/840 16D SI | 4511622 |
|
| Blitz Sq M Double 31W/840 40D SI | 4511632 |
|
| Blitz Sq M Double 31W/840 74D SI | 4511642 |
