Arel D/I

The Arel D/I luminaire with a downlight and uplight feature is designed for offices and other public spaces. The luminaires are equipped with a matt anti-glare shield. Suspension mounting. The standard range includes two colour temperatures and sizes. Integrated LED. Suspension fixtures included.

Steel housing, matt aluminium anti-glare shield.
White, RAL 9003.
Protection class I.
Linkable, two 3 x 2,5 mm2 spring terminal blocks, in Dali-models two 5 x 2,5 mm2 spring terminal blocks. The up- and downlights have their own spring terminals.
Installation height 2–4 m.
Integrated LED 54–79 W, 5800–8800 lm.
Colour temperatures 3000 K and 4000 K. CRI > 80 / Ra 80.
MacAdam 3 SDCM.
IP20.
The standard range includes on/off and Dali models.
Ambient temperature range 0 … 25 °C.
Rated lifetime L70 100 000 h (Ta25°C).
Rated lifetime L80 80 000 h (Ta25°C).
Power source service life 50 000 h.
WH = white, DA = Dali, AL = aluminium, MA = matt.

Also available: Casambi, ActiveAhead, Philips SR, 1–10 V and Switch Dim solutions. CRI > 90 / Ra > 90 available by special order. Also available with various connecting cable solutions and a pull switch (on/off and Dali). High gloss anti-glare shield, luminous flux packages 2700–8800 lm and gray color, RAL 9007, also available on request.
